제품 파라미터
성능 파라미터 | |
디스플레이 | 3.5인치 TFT 트루컬러 LCD 디스플레이, 해상도 320*240, 고화질 LED 백라이트 |
치수 | 치수: 96mm×96mm×100mm 홀 사이즈: 92mm×92mm |
마운팅 패널 두께 | 1.5mm~6.0mm |
무게 | 0.37kg |
공급 전원 | (85~264)VAC, (47~63)Hz (옵션 24VDC) |
내부 저장 | 64M Bytes Flash (옵션 96M, 128M) |
외부 덤프 | U disk 지원(표준 USB2.0 통신 인터페이스) |
최대 전력 소비 | 10W |
상대 습도 | (10~85)% (no condensation) |
작동 온도 | (0~50)℃ |
운송 및 보관 조건 | 온도: (-20~60)℃ 상대 습도: (5~95)% (결로 없음) |
배전 사양 | 150mA, 24 VDC |
정전 보호 | 모든 데이터는 플래시 메모리에 저장되어 모든 기록 데이터 및 구성 매개 변수는 정전으로 인한 손실을 방지할 수 있음. 실시간 시계는 정전후 내부 리튬 배터리로 공급. |
알람 출력 | 최대 4채널, 릴레이는 노멀 오픈 접점, 접점 용량 2A/250VAC (저항 부하) |
통신 인터페이스 | 1 way RS-485 통신 인터페이스 |
프로토콜 | Modbus 통신 프로토콜 |
샘플링 간격 | 1s |
입력 신호 | ||||
DC 전압/전류 입력 | ||||
신호 타입 | 최대 허용 오차(%FS) | |||
(1~5)V | ±0.1 | |||
(0~10)V | ||||
(0~5)V | ||||
(4~20)mA | ||||
(0~20)mA | ||||
(0~10)mA | ||||
(0~100)mV | ±0.2 | |||
(-20~20)mV | ||||
(0~20)mV | ||||
온도 입력 (냉접합 오류 없음) | ||||
신호 타입 | 측정 범위 (°C) | 최대 허용 오차(°C) | ||
B | 600 ~ 1800 | ±2.4 | ||
E | -200 ~ 1000 | ±2.4 | ||
J | -200 ~ 1200 | ±2.4 | ||
K | -200 ~ -100 | ±3.3 | ||
-100 ~ 1300 | ±2.0 | |||
S | -50 ~ 100 | ±3.7 | ||
100 ~ 300 | ±2.0 | |||
300 ~ 1600 | ±1.5 | |||
T | -200 ~ -100 | ±1.9 | ||
-100 ~ 400 | ±1.6 | |||
R | -50 ~ 100 | ±3.7 | ||
100 ~ 300 | ±2.0 | |||
300 ~ 1600 | ±1.5 | |||
N | -200 ~ 1300 | ±3.0 | ||
WRe5-26 | 0~ 2310 | ±4.0 | ||
WRe3-25 | 0~ 2315 | ±4.0 | ||
RTD 입력 | ||||
신호 타입 | 측정 범위 (°C) | 최대 허용 오차 (°C) | ||
Cu50 | -50 ~ 150 | ±1.0 | ||
Pt100 | -200 ~ 650 | ±1.0 | ||
Pt1000 | -200 ~ 200 | ±1.0 | ||
참고: 특수 타입의 열 저항은 사용자 정의가 가능 |
출력 신호 | |||||||
알람 출력 | |||||||
신호 타입 | 측정 범위 | 접점 타입 | 접점 rating | 응답 주기 | |||
알람 출력 | 0/1 | 노멀 오픈 점점 | 2A /250VAC | 1 초 | |||
접점 출력 | |||||||
신호 타입 | 범위 (mA) | 최대 허용 오차 (mA) | |||||
전류 출력 | 4 ~ 20 | ±0.025 | |||||
0~20 | ±0.025 | ||||||
0~10 | ±0.025 |
