PCS7 기계식 압력 스위치
특징
■ 압력 범위: 10~ 5000 psi (0.7 ~ 344 bar)
■ 압력 범위에 비해 뛰어난 사이즈
■ 공장 설정 또는 현장 조정 가능
특징
PCS7스냅 동작 마이크로 스위치는 다목적 범용 스위치로 광범위한 유압 및 공압 응용 제품에 사용할 수 있습니다. 성숙한 피스톤/다이어프램 디자인은 매우 넓은 압력 범위에서 우월한 정확도를 제공하며 6000psi 내압 성능을 보장합니다.
조립식 구조는 두 가지 재질의 다양한 압력 연결과 다양한 전기 터미널을 제공합니다. 사용자는 필요에 따라이 모델을 쉽게 구성할 수 있습니다.
제품 파라미터
성능 파라미터 | ||||
압력 범위 | 10 to 5000 psi (0.7 to 344 bar) | |||
스위치 | SPST; SPDT | |||
Wetted Parts Diaphragm | Nitrile (optional EPDM, Viton® or Neoprene) | |||
Fitting | Zinc-Plated Steel (optional 316 Stainless Steel) | |||
전기 터미네이션 | DIN 43650A IP65; Spade Terminals IP00; Flying Leads IP65; | |||
내압 | 6000 psi (414 bar) | |||
파괴 압력 | 9000 psi (600 bar) | |||
인증 | CE | |||
무게 | 0.4 lbs. (0.15 kg) | |||
권장 작동 온도 한계 | ||||
옵션 선택 | ||||
다이어프램 재질 | No option, -10A, -SP or -RD | -RD or -RD and -G | -SP or -10A | |
Nitrile | 15°F to 185°F (-9°C to +85°C) | 15°F to 250°F (-9°C to +121°C) | 15°F to 212°F (-9°C to +100°C) | |
Viton® | 0°F to 185°F (-18°C to +85°C) | 0°F to 250°F (-18°C to +121°C) | 0°F to 212°F (-18°C to +100°C) | |
EPDM | 10°F to +185°F (-23°C to +85°C) | -10°F to +250°F (-23°C to +121°C) | 10°F to +212°F (-23°C to +100°C) | |
Neoprene | -10°F to +185°F (-23°C to +85°C) | -10°F to +185°F (-23°C to +85°C) | -10°F to +185°F (-23°C to +85°C) | |
전기 스위치 등급 | ||||
옵션 선택 | AC | DC | ||
No option or -RD | 5 amps @ 125/250 Volts | 5 amps resistive, 3 amps inductive @ 28 Volts | ||
-G only or -RD with -G | 1 amp @ 125 Volts | 1 amp resistive, 0.5 amp inductive @ 28 Volts | ||
-10A only or -SP without -G | 10.1 amps @ 125/250 Volts | — | ||
-SP with -G
| 2 amps @ 125/250 Volts | — | ||
참고 : 스위치는 온도가 저온 한계보다 낮을 경우 작동할 수는 있지만 설정 포인트와 불감 대가 증가합니다. 자세한 내용은 당사에 문의하십시오.
