PCPR01 데이터 로거 레코더
특징
■ 최대 18개의 범용 입력 채널
■ 최대 4개의 알람 출력 릴레이
■ 50mA의 배전 출력
■ 통신 타입 : RS485, Modbus RTU
■ USB 데이터 전송 인터페이스
■ 다중 디스플레이 기능 : 디스플레이 방식 선택 가능
■ 날짜 및 시간 검색 기능을 사용하여 기록 데이터 검색 가능
■ 3.5 인치 TFT 컬러 LCD (320 x 240 픽셀)
■ Dust- and splash-proof 앞면 패널
■ 전원 고장 보호 : 플래시 메모리에 저장된 모든 데이터는 정전시 모
든 이전 데이터 및 파라미터는 손실되지 않도록 합니다. Real time
clock는 리튬 배터리로 전원을 공급
■ 다양한 작업을 위한 소프트웨어 : 분석, 세킹 및 수집 기능
제품 파라미터
메인 파라미터 | ||||
디스플레이 | 본 제품은 5인치 TFT 트루 컬러 LCD 화면, 해상도는 320 * 240, 선명한 백라이트, 세면은 거의 제로 시각 각도여서 넓은 시야를 제공. | |||
외형 사이즈 | 외형 치수:96mm×96mm×96mm 오프닝 사이즈:92mm×92mm | |||
장착 패널의 두께 | 1.5mm~6.0mm | |||
무게 | 0.37kg | |||
전기 공급 | (176~264)VAC,47~63Hz | |||
내부 저장 | 48M bytes Flash | |||
외부 저장 | U disk support (표준 USB2.0 통신 인터페이스) | |||
최대 소비 전력 | 20VA | |||
상대 습도 | (10~85)%RH (No condensation) | |||
작동 온도 | (0~50)℃ | |||
운송 및 보관 조건 | 온도 (-20~60)℃, 상대 습도 (5~95)%RH (No condensation) Altitude: <2000m, 특수 사양 제외 | |||
입력 신호 | ||||
전압 / 전류 입력 타입 | 최대 허용 오차 (% FS) | |||
(1~5)V | ±0.1 | |||
(4~20)mA | ±0.2 | |||
열전대 입력 유형 | 측정 범위 (℃) | 최대 허용 오차 (℃) | ||
B | 600 ~ 1800 | ±2.4 | ||
E | -200 ~ 1000 | ±2.4 | ||
J | -200 ~ 1200 | ±2.4 | ||
K | -200 ~ -100 | ±3.3 | ||
-100 ~ 1300 | ±2.0 | |||
S | -50 ~ 100 | ±3.7 | ||
100 ~ 300 | ±2.0 | |||
300 ~ 1600 | ±1.5 | |||
T | -200 ~ -100 | ±1.9 | ||
-100 ~ 380 | ±1.6 | |||
R | -50 ~ 100 | ±3.7 | ||
100 ~ 300 | ±2.0 | |||
300 ~ 1600 | ±1.5 | |||
N | -200 ~ 1300 | ±3.0 | ||
RTD 입력 타입 | 측정 범위 (℃) | 최대 허용 오차 (℃) | ||
Cu50 | -50 ~ 140 | ±1.0 | ||
Pt100 | -200 ~ 800 | ±1.0 |
NOTE:특수 RTD를 사용자가 정의 할 수 있습니다. 예: Pt1000등
출력 신호 | ||
타입 | 알람 출력 | |
척도 범위 | 0/1 | |
Contact 타입 | Normally open contacts | |
Contact capacity | 2A /250VAC | |
응답 주기 | 1 초 |
