지금 위치: WT 홈 > 제품 > 압력 트랜스미터

  • PCM3300 건설 기계용 압력 트랜스미터

PCM3300 건설 기계용 압력 트랜스미터

특징

완전 스테인레스 스틸 구조

우월한 안정성

소형, 경량

보호 등금 IP66

통합 디자인, 누출의 잠복 위험이 없고 안정성 우월

대량 생산에 적합한 성숙한 공정

방진, 내충격



응용

공압 제어

사출 성형기 압력 제어

공기 압축기

야금, 광업 기계

고압 공압 제어 시스템


제품 파라미터


성능 파라미터


압력 범위

01MPa…60MPa


압력 레퍼런스

G


정확도

0.5%FS


온도 드리프트

±0.15%FS/10K


응답 시간

≤2ms


과압

2X 압력 범위


파열 압력

5X 압력 범위


수명

≥1×106 pressure cycles


온도 보상 범위

-2085℃


작동 온도 범위

-40125℃


보관 온도 범위

-40125℃


절연 저항

≥100MΩ/500VDC(200MΩ/250VDC)


내진동

Sine curve: 20g, 25Hz2kHz; IEC   60068-2-6


Random: 7.5grms, 5Hz1kHz; IEC 60068-2-64


보호 등급

Table 참조: 전기 연결 및 배선 모드


압력 포트 재질

17-4PH


출력 및 공급 전원

코드

B1

B3

B2

B7

B6

출력

420mA

05V

15V

010V

0.54.5V R/M

공급 전원

1230VDC

1230VDC

1230VDC

1230VDC

5VDC


회사 경쟁 우위

Mass production

We have one production center in Nanjing and one production center in Anshan with 20,000㎡plant and 170 units of production equipments. The main annual capacity of sensors is about 2,000,000 pieces.

Imported equipments

We imported 20 sets of pressure controller and 150 units of testing ovens to our production line.

Informatization management

We have the information management system of CRM, PLM, ERP, MES and DINGDING etc.

Comprehensive testing

We have our own lab and testing equipment such as lightning stroke, surging, static electricity, vibration, high-low temperature impact test and helium mass-spectrum leak detection.
